KEYENCE IG Series - Manual (Page 155)

A-5 IG-E
Append
ix
Transmitter/Receiver
reverse connection error.
The transmitter and receiver
are reversed. Connect the transmitter and receiver correctly.
"Sensor Head Connection" (page 2-12)
Receiver error
The receiver is not connected
to the sensor amplifier. Connect the receiver correctly.
"Sensor Head Connection" (page 2-12)
The sensor head cable con-
nector is not connected prop-
erly. Make the connection again.
"Attaching the sensor head cable connector
(OP-84338)" (page 2-14)
The receiver is broken.. Replace the receiver.
The sensor head cable of
receiver is damaged.
Replace the sensor head cable.
Transmitter laser error
The laser of the transmitter is
broken.
Replace the transmitter.
Transmitter error
The transmitter is not con-
nected to the sensor amplifier. Connect the transmitter correctly.
"Sensor Head Connection" (page 2-12)
The sensor head cable con-
nector is not connected prop-
erly. Make the connection again.
"Attaching the sensor head cable connector
(OP-84338)" (page 2-14)
The transmitter is broken. Replace the transmitter.
The sensor head cable of
transmitter is damaged.
Replace the sensor head cable.
Model mismatch error
The type (measurement
range) of transmitter and
receiver does not match.
Replace with the same type (measurement
range) of the transmitter and receiver.
Receiver EEPROM
error
Reading/writing the nonvola-
tile memory (EEPROM) stor-
age data failed.
Turn the power on again.
Data has been written in the
nonvolatile memory
(EEPROM) over half-million
times and malfunction
occurred.
Replace the transmitter and receiver.
Head error (Regis-
ter the standard
waveform)
The standard waveform can
not be registered.
Do not turn off the sensor head or disconnect it
from the sensor amplifier while registering the
standard waveform.
Register the Standard Waveform (Gain adjust-
ment) again.
"3-4 Registering the Standard Waveform
(Gain adjustment)" (page 3-9)
Error displays Error contents Corrective actions
T V
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
'T*
GO
HOLD CALC CHECK
Displays alternately
T
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
'T*
GO
HOLD CALC CHECK
.#5'4
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
'T*
GO
HOLD CALC CHECK
V
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
'T*
GO
HOLD CALC CHECK
T#P)G
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
'T*
GO
HOLD CALC CHECK
T''2
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
'T*
GO
HOLD CALC CHECK
#.K)P
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
'T*
GO
HOLD CALC CHECK
