KEYENCE IG Series - Manual (Page 118)

5-6 IG-E
5
Specific
a
tion
s
5-3
Dimensions
IG-1000/IG-1050 unit: mm
*1 Cable specification : IG-1000 12 cores, Nominal cross-section area brown/blue: 0.20 mm
2
, others 0.15 mm
2
: IG-1050 8 cores, Nominal cross-section area: 0.15 mm 2
*2 Not mounted on the IG-1000.
End unit (OP-26751) unit: mm
Sensor Amplifier
Cable diameter: φ 4.8
Cable diameter: φ4.7 Cable length: 2 m* 1
28.3
42.4
37.4
17.4
18.5 18.5 (4.8)*
2
1.9*
2
8.9
20 21.6 35.4
76.3 Min. 15
Min. 15
17.6 When the cover is open: Max. 109.2
Max.
135°
3
53.8
35.4 9.2
20.8
6
(22.6)
