6-6 Menu Bar
6-27 IG-E
6
IG Config
u
ra
tion Softw
a
re (
IG-
H1)
„ Transfer the configuration data to the IG
From the menu, select [Communication]
o[Transfer the configuration data to IG].
The configuration data is transferred to the IG Series.
"Transfer of Configuration data" (page 6-19)
„ Key Lock
From the menu, select [Communication]
o[Key lock].
The [Key lock] dialog box appears. When [Lock] is selected and [Transfer] is clicked, the IG
Series is locked.
"Key Lock Button" (page 6-24)
„ Initial reset (Initialize)
From the menu, select [Communication]
o[Initial reset].
The [Initial reset(Initialize)] dialog box appears.
When selecting the sensor amplifier to perform the initial lock and click [Execute], the
confirmation dialog box appears.
When [Yes (Y)] is clicked, the selected sensor amplifier is initial-reset (initialized).
"3-5 Initial Reset (Initialize)" (page 3-10)
„ Communication Settings...
From the menu, select [Communication]
o[Communication settings].
The [Communication settings] dialog box appears.
For information about the setting procedure, refer to " Start" (page 6-7).
The display language for the IG Configurator is switched.
„ Japanese
From the menu, select [Language]
o[Japanese].
When the IG Configurator is restarted, the display language is set to Japanese.
„ English
From the menu, select [Language]
o[English].
When the IG Configurator is restarted, the display language is set to English.
Reference This procedure can be performed by clicking the [Transfer] button on the tool
bar.
Reference This procedure can be performed by clicking the [Key lock] button on the tool
bar.
Language
