3 part names and functions, Sensor amplifier unit, Part names and functions -9 – KEYENCE IG Series User Manual
Page 19: Sensor amplifier unit -9, Part names and functions
1-9
1
Bef
ore U
s
e
IG-E
1-3
Part Names and Functions
DIN rail mount type (IG-1000/IG-1050)
*1 When shipped from the factory, the protective cover for expansion slots is installed.
*2 It is not installed on the main unit (IG-1000).
Panel mount type (IG-1500/IG-1550)
*1 It is not installed on the main unit (IG-1500).
*2 When shipped from the factory, the protective seal is attached.
Sensor Amplifier Unit
Expansion unit connector*
1
Amplifier control
unit cover
Sensor head connector (Transmitter side)
Amplifier control unit
Sensor head connector (Receiver side)
Expansion unit
connector*
2
Power/Input-output
cable connector
Expansion unit connector
(upper)*
1
Expansion unit connector (lower)*
2
Sensor head connector (Transmitter side)
Sensor head connector (Receiver side)
Amplifier control unit
