84
Command ASCII HEX Description
Piece Wt.
Entry
%9 B9h
Allows a piece weight to be entered serially. For example, 0.10%9 will
enter a piece weight of 0.10.
Print W
or
P
57h, 0Dh
Initiates print function. Print restrictions (P200-P212) will be adhered to.
Requires both hex values, 57h followed by 0Dh.
Zero Z 5Ah, 0Dh
Initiates zero function. Zero restrictions (118) will be adhered to. Requires
both hex values, 5Ah followed by 0Dh.
is a carriage return, decimal value 013, hex value 0Dh.
D
ISPLAY
C
APTURE
U
TILITY
The Display Capture Utility sends the current display information out of the comm port when the extended ASCII
character represented by decimal 149 (hex: 95h) is received through the comm port. Entering a decimal 149 from a
computer keyboard can be accomplished by turning on the Num Lock and holding down the ALT key while typing the
desired decimal number on the keyboard keypad (for example, 149).
The Display Capture Utility must have NTEP disabled in order to function.
E
XAMPLE #1
The scale is in the weigh mode with the gross weight displayed (for example, 15.00).
Input: The extended ASCII character represented by decimal 149 (hex: 95h) is received through the comm port.
Output: “15.00 lb Gross ” is sent out the comm port.
E
XAMPLE
#2
The scale is in setup at P110 Full Scale.
Input: The extended ASCII character represented by decimal 149 (hex: 95h) is received through the comm port.
Output: “P110 F.S. 100.00 ” is sent out the comm port.
Time and Date Setup (Model 350)
The time and date feature is stored as non-volatile (time/date setting will not be lost when the unit power is
reset). The time/date parameter is available in the first two fixed transmits (See Transmit Selection on page 50)
and can be included in a custom transmit (See Custom Transmit Setup on page 55).
Upon power up and with P502 set to Enabled, the display will toggle Enter ~ Date~01.01.70. If the date
is acceptable, press the 1 .
To enter the date from the Enter~date~01.01.70 prompt
EXAMPLE: 01.09.04 (January 9, 2004)
1. Press to toggle through the numbers to enter the month.
DISPLAY READS X 1
