102
To install the panel mount tag:
1. Remove the electronics.
2. Carefully score the case so the drill will not slip.
3. Drill the mounting holes with a 1/16” drill.
4. Gently tap the drill pins to secure the label to the case.
5. Clean out the case.
6. Re-install the electronics.
Damage to the case or electronics is not covered by warranty.
The NTEP panel mount requirements are applicable only to the Model 350 die cast model and panel mount kit.
OMIL Requirements
The International Organization of Legal Metrology is an inter-governmental body which harmonizes the national
metrology regulations of its world wide members. A list of regulation publications may be obtained from the Bureau
International de Métrologie Légale (BIML) in Paris, France.
In order to configure the Model 350 to comply with OIML requirements, parameter P410-Euro must be enabled. Doing
so will ensure the following:
• An over-load condition will result when the gross weight exceeds nine graduations over the full scale
capacity.
• Full scale capacity is always referenced from the last zero calibration reference, not the last zero acquired
by pressing " .
Most NTEP requirements will also apply. See the Other Requirements section below for additional considerations.
Other Requirements
Several parameters must be considered on an individual basis as their configuration may vary with different
applications. These parameters include, but are not limited to:
Parameter Description C OMMENT
P110 Full Scale Capacity Verify proper scale capacity.
P111 Division Size
Verify that the maximum allowable number of scale divisions are not
exceeded.
P112 Zero Track Verify required selection.
P114 Stability Verify required selection.
P118 Zero Range Verify required selection.
P212 Print Stability Verify required selection.
Figure 36: Panel Mount Unit - Serial Number Tag (Die Cast Model)
