81
3. Press 1 or
(
to set a new fill target of 400 lbs.
DISPLAY READS XTarg1 ~ 400
4. Press 1 or ( to select the Pre-Act 1 (subset) value of 28 lbs.
DISPLAY READS XPA 1 ~ 28
5. Press 1 or ( to select the Pre-Act 2 (subset) value of 1.5 lbs.
DISPLAY READS XPA 2 ~ 1.5
6. Press 1 or
(
to select a new Pre-Act 2 value of .5 lbs.
DISPLAY READS XPA 2 ~ .5
7. Press ! to display the current Gross Weight.
DISPLAY READS X15.12
E
XAMPLE
(P
ERCENTAGE
C
HECK
-W
EIGHING
)
With a system set up to check-weigh ice cream containers, the following settings might be used to guarantee container
weights from 1.98 to 2.04 lbs.:
Parameter Setting
Acceptable Check-
weigh Values
Comments
Target = 2.00 Desired container weight.
Percent Lo Value = 1 2.00 * .01 = 0.02
Low acceptable range =
1.98 to 2.00.
Percent Hi Value = 2 2.00 * .02 = 0.04
High acceptable range =
2.00 to 2.04.
Absolute Check-Weighing
This program is commonly used for check-weigh applications. After a target weight is entered, upper and lower
tolerances are entered as absolute values. Over and Under tolerances are also entered as absolute values. The desired
target may be based on gross weight, net weight, or quantity (if counting is enabled). Only the annunciators will light to
indicator the setpoint status. Physical setpoints cannot be added at this time. The setpoint modules will be available in
the near future and will be installed in a safe area hub.
Table 24: Setpoint Setup (Absolute Check-Weighing)
Setpoint Selection Function Description
P5100.6 ChecA Check-weigh by absolute value.
P5101.-- Targ1 Absolute target value.
P5102.-- Lo Low acceptance value.
P5103.-- Hi High acceptance value.
P5104.0 Based
Select from Net, Gross or Count
(Quantity).
See Key-In Parameters on page 43 for instructions on using front panel keys for entering data.
