61
Analog Output Calibration
This section requires firmware rev 010 or later.
Table 16: Analog Output Calibration Parameters
P ARAMETER
S ETTING
D ISPLAYED
N AME
D ESCRIPTION T YPE / CHOICES (*=D EFAULT )
P61200 10oFF
Value required to precisely output 0V in 0 –
10V output mode (i.e. offset). Numeric Entry:
0 to 15,000
2,923*
P61201 10Gn
Value required to precisely output 10V in 0
– 10V output mode (i.e. gain). Numeric Entry:
50,000 to 65,535
61,027*
P61202 0oFF
Value required to precisely output 0 mA in
0 – 20 mA output mode (i.e. offset). Not adjustable:
0*
P61203 0Gn
Value required to precisely output 20 mA in
0 – 20mA output mode (i.e. gain). Numeric Entry:
50,000 to 65,535
54,555*
P61204 4oFF
Value required to precisely output 0 mA in
4 – 20 mA output mode (i.e. offset). Numeric Entry:
0 to 15,000
10,910*
P61205 4Gn
Value required to precisely output 20 mA in
4 – 20mA output mode (i.e. gain). Numeric Entry:
50,000 to 65,535
54,555*
P61206 Srln
Analog option board serial number. Numeric Entry:
0* - 4,294,967,295
The analog output calibration procedure establishes explicit zero and full scale values for each of the three analog
output modes: 0 – 10V, 0 – 20 mA and 4- 20 mA. There are five adjustment values for the analog option, located at the
information parameters P61200 through P61205, that allow the zero and full scale output of each mode to be adjusted
to exact values. This allows the analog option to be configured to match the needs of the system being connected to its
outputs.
The calibration values for each of these modes has been determined at the factory. These values are provided on paper
with each board to make calibrating the analog option a simple process. Each analog option board can be identified by
its serial number, which is entered in the unit during the calibration process.
E
NTERING
A
NALOG
C
ALIBRATION
V
ALUES
An example of the printout included with each analog option kit follows below:
100%s23640%i%e Access Setup Modes, Allowing Changes
60100%s%e P60100. c1998-GSE-
60101%s%e P60101. 0350p01009
60102%s%e P60102. 06-30-2000
60200%s%e P60200. BrdSn573192
60201%s%e P60201. AuditTrail Euro 00001
60202%s%e P60202. InsSn329074
60203%s%e P60203. AuditTrail Cal. 00025
60204%s%e P60204. AuditTrail Setup 00050
61200%s2923%e P61200. 10off 2923
61201%s61027%e P61201. 10 Gn 61027
