Table 20: Setpoint Setup (Discharge)
Setpoint
Selection
Function
Description
P5100.1 Discharge
Select
discharge setpoint operation.
P5101.--
Targ1
Final dispensed target value.
P5104.0
Based
Select between net or count (quantity)
P5105.--
PA 1
Pre-act 1 value (fast-to-slow value; 0 for single-speed).
P5107.0 Start
1
Setpoint activation method.
P5109.--
PA 2
Pre-act 2 value (final cutoff).
P5110.1
Learn 2
Learn feature for pre-act 2.
P5114.1
PrAc 1
Pre-act 1 available as subset in Weigh Mode.
P5115.1
PrAc 2
Pre-act 2 available as subset in Weigh Mode.
P5116.1
Pause
Keypress invokes pause.
See Key-In Parameters on page 43 for instructions on using front panel keys for entering data.
A
CTIVATION
M
ETHOD
(D
ISCHARGE
)
The dispensing activation is limited to
#
or a remote key input. The deactivation of the setpoints is automatic. The
desired target may be based on net or quantity (if counting is enabled). See Activation Methods (General) on page 63
for activation details.
Discharge Status
Annunciator Status
Setpoint Status (Requires Setpoint Option Board)
Fast Discharge
SP 1 & SP 2
Illuminated
Relay 1 and 2 Contacts Closed
Slow (or Single-
Speed) Discharge
SP 1 Illuminated
Relay 1 Contacts Closed
Fill Done or Pause
SP 1 & 2 Off
Relay 1 and 2 Contacts Open
P
RE
-
ACTS
(D
ISCHARGE
)
Pre-act 1 is used for dual-speed dispensing. Pre-act 1 specifies when the system should switch from fast-discharge to
slow-discharge. When using a single-speed device, pre-act 1 should be set to 0 from the Setup Mode. P5114 should
also be disabled to prevent pre-act 1 from appearing as a subset of the target in the Weigh Mode. Pre-act 2 specifies the
point where the final cutoff should occur, regardless of a single-speed or dual-speed operation. See Pre-acts (General)
on page 64 for details on the operational functions of pre-acts.
Pre-act 1 controls setpoint 2. Pre-act 2 controls setpoint 1.
L
EARN
F
EATURE
(D
ISCHARGE
)
Pre-act 2 has the learn feature available which allows the indicator to automatically adjust the final cutoff based on
changing environmental conditions. See Learn Feature (General) on page 64 for learn feature details.
P
AUSE
F
EATURE
(D
ISCHARGE
)
The standard pause feature (keypress, remote key closure or both) is available for the discharge operation. See Pause
Feature (General) on page 64 for pause function details.
