68
Fill
The fill program is used for single-speed or dual-speed filling operations. The dual-speed fill operation allows for both
a fast and a slow fill mode. During a fast-fill, setpoints 1 and 2 are activated. During a slow-fill or single-speed fill,
only setpoint 1 is activated.
Table 18: Setpoint Setup (Fill)
Setpoint Selection Function Description
P5100.1 Fill Select Fill Setpoint Operation
P5101.-- Targ1 Final Fill Target Value
P5104.0 Based Select between Net or Quantity
P5105.-- PA 1 Pre-Act 1 Value (Fast-to-Slow Value; 0 for Single-Speed)
P5107.0 Start 1 Setpoint Activation Method
P5109.-- PA 2 Pre-Act 2 Value (Final Cutoff)
P5110.1 Learn 2 Learn Feature for Pre-Act 2
P5114.1 PrAc 1 Pre-Act 1 Available as Subset in Weigh Mode
P5115.1 PrAc 2 Pre-Act 2 Available as Subset in Weigh Mode
P5116.1 Pause Keypad Press invokes Pause
See Key-In Parameters on page 43 for instructions on using front panel keys for entering data.
A
CTIVATION
M
ETHOD
(F
ILL
)
The fill begins with the selected activation method. The deactivation of the setpoints is automatic. The desired target
may be based on net or quantity (if counting is enabled). See Activation Methods (General) on page 63 for activation
details.
Fill Status Annunciator Status Setpoint Status (Requires Setpoint Option Board)
Fast Fill SP 1 & SP 2 Illuminated Relay 1 and Relay 2 Contacts Closed
Dribble Fill (or Single-
Speed Fill)
SP 1 Illuminated Relay 1 Contacts Closed
Fill Done or Pause SP 1 & SP 2 Off Relay 1 and Relay 2 Contacts Open
P
RE
-
ACTS
(F
ILL
)
Pre-act 1 is used for dual-speed filling. Pre-act 1 specifies when the M350 should switch from fast-fill to slow-fill.
When using a single-speed device, pre-act 1 should be set to 0 from the Setup Mode. P5114 should also be disabled to
prevent pre-act 1 from appearing as a subset of target in the Weigh Mode.
Target – [
(% set at P5012
)
•
Target ]
Bargraph segment weight = 100
8.5
Although the setpoint annunciators are not motion-inhibited, the setpoint relay outputs will not activate
until a no-motion condition exists.
