Setpoint

Selection

Function

Description

P5137.1

Rstb 2

Reset 2 stability setting.

P5141.1

Base 3

Select from Net, Gross or Count (Quantity) for Setpoint 3.

P5142.0

Act 3

Activate setpoint 3 when weight is above or below.

P5143.--

Targ 3

Setpoint 3 target for weight to either rise above or fall below.

P5144.0 Stbl

3

Setpoint

3 stability setting.

P5145.0

Rset 3

Reset selection for setpoint 3.

P5146.--

Rtrg 3

Value for reset. *Only available if “Value” is selected for Reset 3.

P5147.1

Rstb 3

Reset 3 stability setting.

S

ETPOINT

A

CTIVATION

(I

NDEPENDENT

)

Independent Setpoints can be activated when either the gross weight, net weight or quantity (if counting is enabled) is
above or below a target value. When an independent setpoint is set to Activate Above, the setpoint will activate when
the selected mode (gross, net or quantity) is equal to or above the target. When set to Activate Below, the selected
mode must actually be below the target.

A setpoint option board may be installed to allow the M350 to directly control lights, buzzers, valves or
relays (see Setpoint Card Connections on page 26). Also, the setpoints can be configured to ignore or heed
the stability setting (P114).

Independent Status

Annunciator Status

Setpoint Status (Requires Setpoint Option Board)

Setpoint 1 Active

SP 1 Illuminated Relay

1

Closed

Setpoint 2 Active

SP 2 Illuminated Relay

2

Closed

Setpoint 3 Active

SP 3 Illuminated Relay

3

Closed


Independent Setpoint Reset (deactivation) choices:

Parameter

Setting

Reset Choice

Description

P51x5.0 Tare

Setpoint deactivates with

#

.

P51x5.1

Remote Key

Setpoint deactivates with Remote Key closure.

P51x5.2 Auto

Setpoint deactivates when weight returns to +/- 5 graduations of zero and
stabilizes.

P51x5.3 Non-Latched

Setpoint deactivates when weight value is in a range opposite of the
activation setting.

P51x5.4

Reset Value

Setpoint deactivates when weigh reaches a second value and stabilizes.

The Pre-Acts, Learn Mode, and Pause Feature options are not applicable to Independent Setpoint
operation.

C

HANGING

T

ARGETS FROM THE

W

EIGH

M

ODE

(I

NDEPENDENT

)

When Independent Setpoints are configured in the setpoint setup, Targ 1, 2 and 3 automatically become available

modes for the

!

key. An entry followed by

1

or

(

changes the currently viewed target. If the reset for a

setpoint is set to ‘value’, then pressing

1

or

(

alone will allow access to the subset of the target. Rtrg 1, 2 and 3

are the respective subsets for Targ 1, 2 and 3. See Changing Targets from the Weigh Mode (General) on page 65 for
detailed instructions on changing target values from the Weigh Mode.
