83
E
XAMPLE
(A
BSOLUTE
C
HECK
-W
EIGHING
)
With a system set up to check-weigh 50 lb. cement bags, the following settings might be used check-weigh bag from
49.5 to 51.5 lbs.:
Parameter Setting
Acceptable Check-Weigh
Values
Comments
Target = 50.00 Desired bag weight.
Low Value = 49.50 49.50 – 50.00 lbs.
Low acceptable range
= 49.50 to 50.00 lbs.
High Value = 51.50 50.00 – 51.50 lbs.
High acceptable range
= 50.00 to 51.50 lbs.
Remote Key Operation
The Model 350 and Model 355 have four selectable remote key operations to choose from: Print, Tare, Zero and
Setpoint. Only one of these operations may be assigned to the remote key input. Table 25 describes the available
remote key operations. See Remote Key Connection on page 12 for information on connecting a remote key input
device.
Table 25: Remote Key Operations
Remote Key
Selection
Function Description
P800.00 None Remote key disabled.
P800.01 Print
Initiates print function. Print restrictions (P200 –
P212) will be adhered to.
P800.02 Tare
Initiates tare function. Tare restrictions (P161 -
P169) will be adhered to.
P800.03 Zero
Initiates zero function. Zero restrictions (P118)
will be adhered to.
Tare, Zero and Print functions will be delayed according to the stability setting (P114). If a setpoint
operation is configured to use the remote key as an activation method, the P800 setting is over-ridden.
Remote Serial Operation
Table 26: Remote Serial Operation
Command ASCII HEX Description
Print
%p
F0h Initiates print function. Print restrictions (P200 – P212) will be adhered to.
Select %s F3h Performs a parameter or mode select operation.
Tare %t F4h Initiates tare function. Tare restrictions (P161 - P169) will be adhered to.
Units %u F5h Toggles between displayed units of measure.
Zero %z FAh Initiates zero function. Zero restrictions (P118) will be adhered to.
Enter %e E5h
Enters preceding data into selected register. Also toggles through selections in
Setup Mode.
