1
C
HAPTER
1:I
NTRODUCTION
Thank you for selecting the GSE Model 350/355 Indicator. The Model 350 and Model 355
continue the GSE tradition of Excellence in Weighing and Counting Technology. A properly
installed and maintained Model 350 or Model 355 will provide many years of reliable, accurate
performance.
The chapters of this manual focus on various aspects of the Model 350/355:
Chapter 1: Introduction
Features and Specifications.
Chapter 2: Indicator Installation Mounting and wiring connections.
Chapter 3: Option Installation
Installing and setting up options.
Chapter 4: Configuration Using the Model 350/355.
Chapter 5: Calibration Calibrate the indicator to a scale.
Chapter 6: Legal for Trade Troubleshooting help and error messages.
Chapter 7: Troubleshooting Troubleshooting help and error messages.
Standard Features
The Model 350 and 355 include built-in functions that you can enable through the Indicator Setup. Refer to Chapter 4:
Configuration for information on the setup and operation of the following standard functions:
• Check-weighing
• Fill, two-speed, single ingredient
• Batch, three ingredients, single-speed
• Loss-in weight, two-speed emptying
• Independent setpoints
• Parts counting
• Remote key operation
• Selectable, built-in data transmission formats
• Custom data transmissions
Specifications
PERFORMANCE
Full Scale (F.S.)
Selectable 0 to 999,990
Resolution 20-bit A/D converter, 100,000d displayed
±500,000d internal
A/D Conversion 60 Hz
Zero Track 0 – 100% of F.S.
Operating Temperature -10 °C to +40°C
Units of Measure lb, kg, oz, g, lb oz
ELECTRICAL
Power Requirement
350 Zinc Die Cast Enclosure
