82
S
ETPOINT
A
CTIVATION
(A
BSOLUTE
C
HECK
-W
EIGHING
)
In order for the annunciators or setpoints to activate, the displayed value must be at least five graduations above zero. A
setpoint option board may be installed to allow the Model 350 to directly control lights, buzzers, drop-gates, or reject
devices.
Check-Weigh
Status Annunciator
Status Annunciator
Color (LED)
OVER
SP 1
Illuminated
Red
GOOD
SP 2
Illuminated
Green
UNDER
SP 3
Illuminated
Yellow
The Pre-Acts, Learn Mode, and Pause Feature options are not applicable to check-weigh operation.
C
HANGING
T
ARGETS FROM THE
W
EIGH
M
ODE
(A
BSOLUTE
C
HECK
-
W
EIGHING
)
When Check-Weigh by Absolute is configured in the setpoint setup, the Targ 1 value automatically becomes an
available mode for the ! key. Keying in a value before pressing 1 changes Targ 1. Targ 1 is entered as an
absolute value. Pressing 1 alone gives access to the subsets. Lo and Hi are the subsets for Targ 1. Lo and Hi are also
entered as absolute values.
To change targets from the Weigh Mode:
1. Press ! to view the current net weight.
DISPLAY READS X0.00
2. Press ! to view the current fill target.
DISPLAY READS XTarg1 ~ 250
3. Press 1 or ( to set a new fill target of 400 lbs.
DISPLAY READS XTarg1 ~ 400
4. Press 1 or ( to select the Pre-Act 1 (subset) value of 28 lbs.
DISPLAY READS XPA 1 ~ 28
5. Press 1 or ( to select the Pre-Act 2 (subset) value of 1.5 lbs.
DISPLAY READS XPA 2 ~ 1.5
6. Press 1 or ( to select a new Pre-Act 2 value of .5 lbs.
DISPLAY READS XPA 2 ~ .5
7. Press ! to display the current Gross Weight.
DISPLAY READS X15.12
