39
Version 1 kits (GSE P/N: 24350B-120B0-- Zinc Die Cast Model and GSE P/N: 24350B-121B0-- Stainless Steel
Model) do not support automatic shutdown.
The original option kits included revision A of the battery option board, PC894. This board did not have the automatic
power off feature. The automatic power off feature cannot be added to this version of the option kit. All of the other
features listed above will function with this version.
Splash Guard Protection
The GSE Dura-Shield (GSE part # 31-70-35578) provides front panel protection for a 350 stainless steel enclosure used
in heavy washdown environments. A clear Lexan® cover, the GSE Dura-Shield adheres to the metal portion of the
front panel and not to the display lens or keypad, shielding the 350 from the elements while leaving the display
unobscured, the keys easily pressed. The Lexan® is abrasion and chemical attack resistant, and non-yellowing.
Use caution when installing any equipment into a washdown environment. Be sure to use a pressure
relief valve (PN# 44-30-5531).
International Transformer - IEC
The Model 350 zinc die cast transformer (GSE P/N 20-20-35190) allows the 350 to run on overseas current. Mounting
tabs and line cords provide installation flexibility, allowing easy mounting to walls, tables, shelves, etc.
Transformers are available for Zinc Die Cast models only.
S
PECIFICATIONS
• Operates on 230VAC input at 50 hz with an output of 20VAC @ 1 Amp max.
• Cord length from transformer to indicator is six feet (two meters) and includes the standard 3-prong Model
350/355 input plug.
• Cord length from the transformer to the IEC (male) plug end is another six feet (two meters).
T
RANSFORMERS
A
VAILABLE
• Model 350 Zinc Die Cast Transformer (GSE part # 20-20-35190)
IEC
LINE CORDS
A
VAILABLE
• GSE part # 22-30-1022 – for use in Australia, Argentina, New Zealand, and China
• GSE part # 22-30-1023 – for use in Chile and Italy
NOTE: The transformers can be ordered separately or with an instrument specified below:
• Model 350 Zinc Die Cast LED Display (GSE P/N 200350-28010)
• Model 350 Zinc Die Cast LCD Display (GSE P/N 200235-28020)
