Setpoint Selection Function Description
P5105.-- PA 1 Pre-act 1 value for vessel fill.
P5106.1 Learn 1 Learn feature for pre-act 1.
P5107.0 Start 1 Setpoint 1 activation method.
P5108.-- Targ 2 Vessel discharge target value.
P5109.-- PA 2 Pre-act 2 value for vessel discharge.
P5110.1 Learn 2 Learn feature for pre-act 2.
P5111.0 Start 2 Setpoint 2 activation method.
P5116.1 Pause Keypad press invokes pause.
See Key-In Parameters on page 43 for instructions on using front panel keys for entering data.
A
CTIVATION
M
ETHOD
(B
OTH
)
The fill and discharge functions begin with their selected activation methods. The deactivation of the setpoints is
automatic. The desired target may be based on net or quantity (if counting is enabled). See Activation Methods
(General) on page 63 for activation details.
Both Status
Annunciator
Status
Setpoint Status (Requires Setpoint
Option Board)
Vessel Fill SP 1 Illuminated Relay 1 Contacts Closed
Vessel Discharge SP 2 Illuminated Relay 2 Contacts Closed
Fill Done or Pause SP 1 & SP 2 Off Relay 1 and Relay 2 Contacts Open
P
RE
-
ACTS
(B
OTH
)
Pre-act 1 is used for vessel filling. Pre-act 1 specifies the point where the final cutoff for the fill should occur. Pre-act 2
specifies the point where the final cutoff for the material discharge should occur. See Pre-acts (General) on page 64
for details on the operational functions of pre-acts.
L
EARN
F
EATURE
(B
OTH
)
Both pre-act 1 and 2 have the learn feature available which allows the indicator to automatically adjust the final cutoff
based on changing environmental conditions. See Learn Feature (General) on page 64 for ‘learn’ feature details.
P
AUSE
F
EATURE
(B
OTH
)
The standard pause feature (keypress, remote key closure or both) is available for the Both operation. See Pause
Feature (General) on page 64 for ‘pause’ functions details.
T
ARGET
C
HANGES FROM THE
W
EIGH
M
ODE
(B
OTH
)
When Both is configured in the setpoint setup, Targ 1 and Targ 2 automatically become available modes for the !
key. An entry followed by 1 or ( changes the currently viewed target. Pressing 1 or ( alone allows
access to the subsets. PA 1 is the subset for Targ 1 and PA 2 is the subset for Targ 2.
Pre-act 1 controls setpoint 1. Pre-act 2 controls setpoint 2.
