Publication 1757-IN032B-EN-P - April 2001

1-58 System Software Upgrade Procedures

9. Click Yes to confirm the action.

10. Click OK.

11. Close NTOOLS.

Updating the 1784-PCIC Network Address

1. On SERVERB, click Start

⇒

Programs

⇒

Rockwell

Software

⇒

RSLinx

⇒

RSLinx to call up the Rockwell Software

RSLinx window.

2. Click Communications

⇒

Configure Drivers to call up the

Configure Drivers dialog box.

3. Select AB_PCIC-1 in the Configured Drivers list box and click

Configure.

4. In the Configure 1784-PCIC window, enter 23 for the new

Network Address for the 1784-PCIC and click OK.

5. Restart SERVERB.

6. On SERVERA, click Start

⇒

Programs

⇒

Rockwell

Software

⇒

RSLinx

⇒

RSLinx to call up the Rockwell Software

RSLinx window.

7. Click Communications

⇒

Configure Drivers to call up the

Configure Drivers dialog box.

ATTENTION

Before continuing, you MUST exit all ProcessLogix
applications and stop all ProcessLogix services on the
SERVERB node.

ATTENTION

Before continuing, you MUST exit all ProcessLogix
applications and stop all ProcessLogix services on the
SERVERA node.
