Full PC Software Installation Procedures 3-15
Installing ProcessLogix
Knowledge Builder
Software
Refer to Installing ProcessLogix Knowledge Builder Software on
page 1-16.
Installing the 1784-PCIC
Card
1. Click Start
⇒
Shut Down and select the shutdown the computer
option.
2. Power down the PC.
3. Install the 1784-PCIC card and attach the ControlNet cables.
Refer to the installation instructions, Publication
1784-IN003A-EN-P for details.
ATTENTION
!
In order to perform correctly, the 1784-PCIC card
MUST have the PAL part number 99640604. If the
1784-PCIC card does not have this PAL, you must
return your card for the update.
Contact Rockwell Automation Technical Support for
more information. Refer to Rockwell Automation
Technical Support in the Preface.
