Publication 1757-IN032B-EN-P - April 2001
3-34 Full PC Software Installation Procedures
Upgrading Hardware
Component Firmware
1. Refer to Loading 1757-PLX52 and TC-MUX021 Boot and
Personality Images on page 2-10 to upgrade the 1757-PLX52
boot and personality images to the current release level.
2. After upgrading the 1757-PLX52, refer to Upgrading Hardware
Component Firmware on page 2-1 to check if other hardware
components require upgrades.
Making Post ProcessLogix
Software Installation
Checks for a
Non-redundant Server
Checking Control Builder Operation and Logging On
Use the following general procedure to log on and check Control Builder
operation on a ProcessLogix Engineering Workstation.
1. Click Start
⇒
Programs
⇒
ProcessLogix Engineering
Tools
⇒
Control Builder.
2. In the Login dialog box, make these entries:
a. Key in >mngr< as the default User Name.
b. Key in >mngr1< as the default Password.
c. Key in the name of the appropriate Server node in the Server
Name field.
3. Click OK.
Enabling the ProcessLogix OPC Server
Refer to Enabling the ProcessLogix OPC Server on page 1-42.
Backing Up a ProcessLogix Server Hard Drive to Tape
Performing backups is an essential part of maintaining your system. You
should back up all the files under the data directory, as well as any user
files you create. Refer to Backing Up a ProcessLogix Server to Tape on
page 1-6.
IMPORTANT
Stop! It is essential that you check the firmware
revision levels for ALL ProcessLogix hardware
components after a ProcessLogix software installation
and/or a component addition or replacement.
Do not proceed until you have upgraded the firmware.
