Rockwell Automation 1757-SWKIT3200 ProcessLogix R320.0 Installation and Upgrade Guide - Manual (Page 176)

Publication 1757-IN032B-EN-P - April 2001
4-12 Additional Redundant Server Procedures
6. On SERVERA, click Start
⇒
Programs
⇒
Rockwell
Software
⇒
RSLinx
⇒
RSLinx to call up the Rockwell Software
RSLinx window.
7. Click Communications
⇒
Configure Drivers to call up the
Configure Drivers dialog box.
8. Click the AB_PCIC-1 in the Configured Drivers list box and click
Configure.
9. In the Configure 1784-PCIC window, enter 24 for the new
Network Address for the PCIC and click OK.
10. Restart SERVERA.
Configuring RSLinx Drivers
for Ethernet Supervisory
Network
1. Verify the settings of the Ethernet Network Interface card to be
used to communicate with the controller.
Navigate in Knowledge Builder to:
Ethernet Implementation Guide
⇒
Configuration
⇒
Setting Up
Drivers and IP Addresses for more information.
2. Configure the IP Address for each controller.
Navigate in Knowledge Builder to:
Ethernet Implementation Guide
⇒
Configuration
⇒
Setting Up
Drivers and IP Addresses
⇒
Configuring and setting IP address for
Ethernet module section for more information.
3. Configure RSLinx drivers.
Navigate in Knowledge Builder to:
Ethernet Implementation Guide
⇒
Configuring additional RSLinx
drivers for more information.
IMPORTANT
If you are using ControlNet for your Supervisory
Network, skip this section.
Refer to Configuring RSLinx Drivers for ControlNet
Supervisory Network on page 4-9.
TIP
A driver must be configured for each controller.
