Publication 1757-IN032B-EN-P - April 2001
Additional Redundant Server Procedures 4-3
Use the following format to make your separate line entries into
this file.
Where:
is:
IP Address
the assigned internet address with no leading zeros. For example, a
typical address could be >192.168.0.1<.
Computer Name
a base name of up to 13 characters, which must be the same for each
ProcessLogix Server in the system.
•
In a redundant Server system, you must append a letter to the
base name to identify the PC’s function in the system architecture
with the letters a and b for the Primary and Secondary Servers,
respectively.
EXAMPLE
For example, if you have a redundant Server
system and you assign a base name of PLX1, the
Computer Name for the Primary Server and
Secondary Engineering Repository Database
(ERDB) would be >PLX1A<, the Secondary Server
and Primary ERDB would be >PLX1B<.
Computer Name0
the computer name appended with a 0 to show its association with
the first Ethernet adapter card.
Computer Name1
the computer name appended with a 1 to show its association with
the second Ethernet adapter card (in a dual Local Area Network (LAN)
system).
EXAMPLE
For example, if you have a redundant Server system
with a dual LAN and a base computer name of
>PLX1<, the Computer Names would be
>PLX1A0<, >PLX1B0<, and >PLX1A1<,
>PLX1B1< for their respective addresses. If you
have a single LAN system, you only need to append
the Computer Name with a “0”.
Comment
any additional descriptive data you want to include for a given
Computer Name.
•
You must begin each entry with the number symbol >#<.
•
An example of a Host file with additional Host name entries and
comments is shown above for reference.
•
The Hosts file includes a default IP address of >127.0.0.1< for a
localhost. Do not delete this default entry from the Hosts file.
