DataSite Configuration Settings Utility (DS Settings) 55
Configure HART Settings
Use HART Settings to configure and send HART command messages.
Open the HART Settings Dialog Box
Follow this step to open the HART Settings dialog box.
•
From the Tools menu, choose HART Settings.
The HART Settings dialog box appears. The file,
HART Block Parameter.hrt, located in the current project directory is
displayed on the project browser file pane.
TIP
Customized function blocks that can be triggered in the
user program to provide HART read/write functions are
also available. For more information, see the DataSite
Customized Function Blocks Reference Manual,
.
TIP
You can also double-click the HART Block Parameter.hrt
file in the project browser file pane to open the HART
Settings dialog box.
