Rockwell Automation 1758-RTU202 DataSite Software User Manual FRN 1.2 - Manual (Page 310)

Publication 1758-UM002D-EN-P - October 2010
310 Extension Modbus Protocol for DataSite Controllers (1758-FLO)
The following table lists the register addresses for records 2…8 of daily history
data. The data type and attribute of each register are the same as those of the
corresponding register for record 1.
There is no event code for command number 22.
49057 float R Reserved
49059 float R User variable 1
49061 float R User variable 2
49063 float R User variable 3
49065 float R User variable 4
Registers for records 2…8 of daily history data
Address Data Type Attribute Description
49067…49097 As above As above Record 2
49099…49129 As above As above Record 3
49131…49161 As above As above Record 4
49163…49193 As above As above Record 5
49195…49235 As above As above Record 6
49237…49267 As above As above Record 7
49269…49299 As above As above Record 8
Return codes for command number 22
Return Code Description
00 OK
01 Meter run is invalid
02 Start date index is invalid
03 Number of records you want to get is invalid
100 Pass code is incorrect
Other Invalid
Registers for record 1 of daily history data (Continued)
Address Data Type Attribute Description
