312 Extension Modbus Protocol for DataSite Controllers (1758-FLO)
The following table lists the register addresses for records 2…8 of hourly
history data. The data type and attribute of each register are the same as those
of the corresponding register for record 1
There is no event code for command number 23.
49055
float
R
EXT (AGA3)/
Uncorrected volume (AGA7)
49057
float
R
Reserved
49059
float
R
User variable 1
49061
float
R
User variable 2
49063
float
R
User variable 3
49065
float
R
User variable 4
Registers for records 2…8 of hourly history data
Address
Data Type
Attribute
Description
49067…49097
As above
As above
Record 2
49099…49129
As above
As above
Record 3
49131…49161
As above
As above
Record 4
49163…49193
As above
As above
Record 5
49195…49235
As above
As above
Record 6
49237…49267
As above
As above
Record 7
49269…49299
As above
As above
Record 8
Return codes for command number 23
Return Code
Description
00
OK
01
Meter run is invalid
02
Start date index is invalid
03
Start time index is invalid
04
Number of records received
100
Pass code is incorrect
Other
Invalid
Registers for record 1 of hourly history data (Continued)
Address
Data Type
Attribute
Description
