DataSite Flow Configuration Utility (DS FloConfig) 139
•
Tube Diameter
This is the inner diameter of tube measured at the reference temperature
specified in the Reference T box.
Configure AGA7 Process Parameters
If you choose the AGA7 gas flow calculation standard, you need to configure
these parameters:
•
Instrument parameters
Instrument Parameters for AGA7 Standard
These instrument parameters are the same for both AGA3 and AGA7
calculation methods:
•
Base pressure
•
Base temperature
•
Pressure type
TIP
For any changes to parameter settings to be applied to the
DataSite controller, you need to click Download.
IMPORTANT
Before downloading any changes to the DataSite controller,
it is recommended that you perform an upload. This helps
prevent modifying information that you did not intend to
change.
