104 DataSite Configuration Settings Utility (DS Settings)
Modbus Register for Signals
This table lists the Modbus registers and their data types, Modbus addresses
and attributes.
Name Data Type Modbus Address Attribute
DI0 BOOL 10001 Read-only
DI1 BOOL 10002 Read-only
DI2 BOOL 10003 Read-only
DI3 BOOL 10004 Read-only
DI4 BOOL 10005 Read-only
DI5 BOOL 10006 Read-only
DI6 BOOL 10007 Read-only
DI7 BOOL 10008 Read-only
DI8 BOOL 10009 Read-only
DI9 BOOL 10010 Read-only
DI10 BOOL 10011 Read-only
DO0 BOOL 00001 Read/write
DO1 BOOL 00002 Read/write
DO2 BOOL 00003 Read/write
DO3 BOOL 00004 Read/write
AI0 U_SHORT 30001 Read-only
AI1 U_SHORT 30002 Read-only
AI2 U_SHORT 30003 Read-only
AI3 U_SHORT 30004 Read-only
AI4 U_SHORT 30005 Read-only
AI5 U_SHORT 30006 Read-only
AI6 U_SHORT 30007 Read-only
AI7 U_SHORT 30008 Read-only
AO0 U_SHORT 40001 Read/write
AO1 U_SHORT 40002 Read/write
PI0 U_INT 30011...30012 Read-only
PI1 U_INT 30013...30014 Read-only
PI2 U_INT 30015...30016 Read-only
