DataSite Flow Configuration Utility (DS FloConfig) 223
Insert a HART Scan Block
Follow these steps to insert a HART scan block.
1.
In the HART Settings dialog box, select the row where you want to
insert the scan block to and click Insert. Alternatively, you can
double-click the row.
Note that you cannot insert data after an empty data block.
An Invalid scan block is inserted.
2.
Double-click the block to edit.
Second byte - when unused
Bit
Description
7
All bits 0 (when a communication error is reported in
the first byte).
6
5
4
3
2
1
0
Second byte - Field Device Status
Bit
Value
Description
7
hex 80
Field device malfunction
6
hex 40
Configuration changed
5
hex 20
Cold start
4
hex 10
More status available
3
hex 08
Analog output current fixed
2
hex 04
Analog output saturated
1
hex 02
Nonprimary variable out of limits
0
hex 01
Primary variable out of limits
