Publication 1758-UM002D-EN-P - October 2010
196 DataSite Flow Configuration Utility (DS FloConfig)
Configure the Scan Settings For integrated modules such as the DataSite controller, the master ports can
directly read/write parameters by accessing the fixed Modbus registers. We
need to set scan blocks of US1 and US2 only when we want to access other
pieces of equipment connected with the two serial ports (COM1, COM2).
Use Scan Settings to match the register addresses of the 1758 controller with
those of the serially connected equipment.
Understand the Scan Blocks
Every scan block corresponds to a scan task. The maximum number of scan
tasks is 128. This table lists the description of each item in a scan block.
Block Type
The block type indicates the category of scan block data.
Scan block parameters and their descriptions
Scan Block Parameter Description
Block type Scan block data category
Address Modbus slave station number of serial communication
equipment connected with COM1 or COM2.
Signal type Signal register category
Scan time Read/Write interval
Master Register Register address where data is saved in the controller,
decided by the user.
Slave Register You can set the read/write data register address of the
slave communication equipment according to the parameter
form of the slave communication equipment register.
Reg_Num The number of read/write data registers.
Err_Cnt The number of times the scan block fails to communicate.
Err_State Scan block communication state.
If the Err_State value is 1, it means the communication has
failed. A value of 0 indicates that the communication is OK.
Remark User comments.
You can enter a note or a tip for the scan block. Note that
this field will not be downloaded to the DataSite controller.
Scan block types and their descriptions
Name Function
US1 block 1758-RTU controller Read-write data of the serial
equipment connected with the serial port COM1.
US2 block 1758-RTU controller Read-write data of the serial
equipment connected with the serial port COM2.
