Publication 1758-UM002D-EN-P - October 2010
148 DataSite Flow Configuration Utility (DS FloConfig)
6. To save this configuration, click Save.
The Save button is located to the right of the Field Signal parameters in
the Meter Run window.
7. Click Download to apply the settings to the DataSite controller.
Valid Range of Gas Characteristics for AGA8 Methods
This table identifies the ranges of gas characteristics for which the AGA8
report can be used.
IMPORTANT
The mole percentage of each component, heating value
and relative density should not exceed the range which is
listed in table 1 of
Valid Range of Gas Characteristics for
AGA8 Methods on page 148 .
Quantity Normal Range Expanded Range
Relative density 0.56…0.87 0.07…1.52
Gross heating value
(1)
(1) Reference conditions are as follows: Combustion at 60 ºF, 14.73 psia; density at 60 ºF, 14.73 psia.
477…1150 Btu/scf 0…1800 Btu/scf
Methane mole percent 45.0…100.0 0…100.0
Nitrogen mole percent 0.0…50.0 0…100.0
Carbon dioxide mole percent 0.0…30.0 0…100.0
Ethane mole percent 0.0…10.0 0…100.0
Propane mole percent 0.0…4.0 0…12.0
Butane mole percent 0.0…1.0 0…6.0
Pentane mole percent 0.0…0.3 0…4.0
Hexane mole percent 0.0…0.2 0…Dew point
Helium mole percent 0.0…0.2 0…3.0
Hydrogen mole percent
0
(2)
(2) The normal range is considered to be zero for these compounds.
0…100.0
Carbon monoxide mole percent
0
(2) 0…3.0
Argon mole percent
0
(2) 0…1.0
Oxygen mole percent
0
(2) 0…21.0
Water mole percent 0.0…0.05 0…Dew point
Hydrogen sulfide mole percent 0.0…0.02 0…100.0
