Identifiers of the process data objects
The identifiers for the process data objects XCAN1_IO ... XCAN3_IO consist of the basic
identifiers and the node address set in C2350:
Identifier = basic identifier + node address
Object
Basic identifier
dec
hex
PDO1
(Process data channel 1)
XCAN1_IO (cyclic process data)
XCAN1_IN
512
200
XCAN1_OUT
384
180
PDO2
(Process data channel 2)
XCAN2_IO (event/time−controlled process data)
XCAN2_IN
640
280
XCAN2_OUT
641
281
PDO3
(Process data channel 3)
XCAN3_IO (event/time−controlled process data)
XCAN3_IN
768
300
XCAN3_OUT
769
301
