System modules
CANaux1_IO (node number 34)
Outputs_CANaux1
l
307
EDBCSXA064 EN 3.2
13.12.2
Outputs_CANaux1
System variables
Variable
Data
type
Signal
type
Address
Display
code
Display
format
Comments
CANaux1_nOutW0_a
integer
analog
%QW34.0
˘
˘
CANaux1_bFDO0_b
BOOL
binary
%QX34.0.0
˘
˘
...
...
CANaux1_bFDO15_b
%QX34.0.15
CANaux1_nOutW1_a
integer
analog
%QW34.1
C2493/1
dec [%]
CANaux1_bFDO16_b
BOOL
binary
%QX34.1.0
˘
˘
...
...
CANaux1_bFDO31_b
%QX34.1.15
CANaux1_nOutW2_a
integer
analog
%QW34.2
C2493/2
dec [%]
CANaux1_bFDO32_b
BOOL
binary
%QX34.2.0
˘
˘
...
...
CANaux1_bFDO47_b
%QX34.2.15
CANaux1_nOutW3_a
integer
analog
%QW34.3
C2493/3
dec [%]
CANaux1_bFDO48_b
BOOL
binary
%QX34.3.0
˘
˘
...
...
CANaux1_bFDO63_b
%QX34.3.15
CANaux1_dnOutD1_p
double
integer
position
%QD34.1
˘
˘
