Troubleshooting and fault elimination
Fault messages
Overview of fault messages, error sources and responses
12
l
245 EDBCSXA064 EN 3.2
System error message Possible settings/response
· Lenze setting
ü Setting possible
Available in
No. Display Source Meaning Code TRIP Messa
ge
Warni
ng
FAIL−Q
SP
Off Drive
PLC
Servo
PLC
ECSxA
x209 float Sys−T Internal System task 2) · ь ь ь ь ь
x210 float Cycl.−T Cyclic task (PLC_PRG, ID 1)
x211 float T Id2 Task with ID 2
x212 float T Id3 Task with ID 3
x213 float T Id4 Task with ID 4
x214 float T Id5 Task with ID 5
x215 float T Id6 Task with ID 6
x216 float T Id7 Task with ID 7
x217 float T Id8 Task with ID 8
x218 float T Id9 Task with ID 9
x220 NoT−FktCredit Internal Not enough technology units
available in the PLC
· ь ь ь
x230 No Program Internal No PLC program loaded · ь ь ь
x231 Unallowed Lib Internal In the PLC program a library
function was called which is
not supported
· ь ь ь
x232 NoCamData Internal Motion profiles (cam data)
are not available
· ь ь ь
x240 ovrTransQueue free
CAN obj.
Overflow of transmit request
memory C0608 · ь ь ь 3) ь ь ь ь
x241 ovr Receive Too many receive telegrams C0609 · ь ь ь
x250 2.Flash Err Internal Access not possible 1)
(FLASH memory damaged or
not available)
· ü
x251 AddData CsErr Internal Checksum error when loading
data into the FLASH memory
x252 AddData DlErr Internal Error when downloading data
into the FLASH memory
(e.g. time−out)
x260 Err NodeGuard Node
Guardin
g
"Life guarding event": The PLC
as a CAN slave has not
received any "node guarding"
telegram within the node
lifetime of the CAN master. C0384 · ь ь ь 3) ь ь ь ь
x: 0 = TRIP, 1 = Message, 2 = Warning, 3 = FAIL−QSP
1) Completely deenergise device after error correction!
2) Can be set in DDS under Project W Exception handling
3) Only for 9300 Servo PLC!
