Lenze ECSCAxxx - Manual (Page 409)

Appendix
Code table
14
l
409 EDBCSXA064 EN 3.2
IMPORTANT Possible settings Code
Selection Lenze/
{Appl.} Designation No.
[C0495] Feedback n 0 Selection of feedback system for
speed control ^ 112
0 Resolver at X7 Standard setting
1 TTL encoder at X8 l Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2 SinCos encoder at X8
3 Absolute value encoder (single−turn) at
X8
4 Absolute value encoder (multi−turn) at
X8
C0497 Nact filter 2.0 Time constant of actual speed
value
0.0 {0.1 ms} 50.0 0.0 ms = switched off
C0504 Activate/deactivate write
protection for RAM memory
l In case of activated write
protection, writing on the
RAM memory via codes or
functions from the function
library LenzeMemDrv.lib not
possible.
^ 381
1 0 0 Write protection RAM block 1 inactive
1 Write protection RAM block 1 active
2 0 0 Write protection RAM block 2 inactive
1 Write protection RAM block 2 active
C0505 0 Offset address within the RAM
block selected via C0506 ^ 381
0 {1} 65532
C0506 1 Selection of the RAM block for
access via C0509
^ 381
1 RAM block 1
2 RAM block 2
C0507 0 Value read from the RAM block
l After reading, the pointer to
the memory address is
automatically incremented by
4 bytes.
^ 381
0 {1} 65532
C0508 0 Value to be written into the RAM
block
l After writing, the pointer to
the memory address is
automatically incremented by
4 bytes.
^ 381
0 {1} 65532
C0509 CmpChecksRa
m
0 Check sum verification ^ 381
0 Inactive Stop the PLC during the check
sum verification to avoid a
time−out when reading back the
code.
1 Active
C0510 ProtAppFlash 0 Write−protection application
FLASH
0 No write protection
1 Write protection is active
