Commissioning
Setting of the feedback system for position and speed control
TTL/SinCos encoder as position and speed encoder
6
l
116 EDBCSXA064 EN 3.2
Codes for feedback system selection
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
[C0490] Feedback pos 0 Selection of feedback system for
positioning control
^ 112
0 Resolver at X7 Standard setting
1 TTL encoder at X8 l Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2 SinCos encoder at X8
3 Absolute value encoder (single−turn) at
X8
4 Absolute value encoder (multi−turn) at
X8
[C0495] Feedback n 0 Selection of feedback system for
speed control ^ 112
0 Resolver at X7 Standard setting
1 TTL encoder at X8 l Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2 SinCos encoder at X8
3 Absolute value encoder (single−turn) at
X8
4 Absolute value encoder (multi−turn) at
X8
Codes for optimising the operation and display
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
[C0419] Enc. setup 110 Encoder selection
l Selection of encoder type
indicated on the nameplate of
the Lenze motor.
l The encoder data (C0420,
C0421, C0427) is set
automatically in accordance
with the selection.
^ 331
^ 115
^ 122
0 Common
110 IT512−5V Incremental encoder with TTL
level
111 IT1024−5V
112 IT2048−5V
113 IT4096−5V
210 IS512−5V SinCos encoder
211 IS1024−5V
212 IS2048−5V
213 IS4096−5V
307 AS64−8V SinCos absolute value encoder
with Hiperface® interface
(single−turn)
Selections 307, 308, 309 are only
possible with operating system
7.0 or higher.
308 AS128−8V
309 AS256−8V
310 AS512−8V
311 AS1024−8V
407 AM64−8V SinCos absolute value encoder
with Hiperface® interface
(multi−turn)
408 AM128−8V
