Appendix
Memories
Temporary codes
l
380
EDBCSXA064 EN 3.2
E4 00 0A 00 01 00 00 00
1C FF 00 00
wSizeHeader = 00 E4
= 228 Byte
hex
wDataType = 00 0A
= 10 (Cam data)
hex
dwVersion = 00 00 00 01
hex
dwRealSize = 00 00 FF 1C
= 65308 Byte
hex
ECSXA295
Fig. 14−1
Header interpretation
14.3.4
Temporary codes
The codes C2500 and C2501 are temporary codes, i. e. the data of these codes
ƒ
does not assign storage space in the EPROM of the drive.
ƒ
cannot be stored with C0003 = 1 in the parameter set of the drive.
ƒ
is lost after switch−off of the drive or after mains failure.
ƒ
is fixedly interlinked with the flag area of the PLC.
I
Tip!
ƒ
Temporary codes are suited for the reception of parameters which are to be
accessed during a switch−on cycle of the ECSxA... axis module only.
ƒ
Furthermore, the codes present the possibility to directly (e. g. via HMI)
access the flag area of the ECSxA... axis module without having to apply a
variable.
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C2500
PLC flag 1 ... 255
^ 380
0
{1}
65535
C2501
PLC flag 256 ... 512
^ 380
0
{1}
65535
