Commissioning
Optimising the drive behaviour after start
Speed controller adjustment
6
l
142 EDBCSXA064 EN 3.2
Parameter setting
ƒ Set the proportional gain (V
pn
) via C0070:
– Enter approx. 50 % of the speed setpoint (100 % = 16384 = n
max
).
– Increase C0070 until the drive becomes instable (pay attention to engine noises).
– Reduce C0070 until the drive runs stable again.
– Reduce C0070 to approx. half the value.
ƒ In the PLC program, the MCTRL_nNAdapt_a variable can be used to change the
proportional gain (V
pn
):
– V
pn
= MCTRL_nNAdapt_a [%] × C0070
– Default: MCTRL_nNAdapt_a = 100 %
ð V
pn
= 100 % × C0070 = C0070
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
C0070 Vp speedCTRL 3.0 Proportional gain of speed
controller (V
pn
)
^ 141
0.00 { 0.01} 127.99
ƒ The reset time (T
nn
) is set via C0071:
– Reduce C0071 until the drive becomes instable (pay attention to engine noises).
– Increase C0071 until the drive runs stable again.
– Increase C0071 to approx. the double value.
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
C0071 Tn speedCTRL 24.0 Reset time − speed controller
(T
nn
)
^ 141
1.0 {0.5 ms} 6000.0
ƒ The derivative gain (T
dn
) is set via C0072:
– Increase C0072 during operation until an optimal control mode is reached,
although the D component is mostly not used in praxis (C0072=0).
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
C0072 Td speedCTRL 0.0 Derivative gain of speed
controller (T
dn
)
^ 141
0.0 {0.1 ms} 32.0
