System modules
CANaux_Management (node number 111)
Inputs_CANaux_Management
l
300
EDBCSXA064 EN 3.2
13.11.1
Inputs_CANaux_Management
System variables
Variable
Data
type
Signal
type
Address
Display
code
Display
format
Comments
CANaux_bCe11Comm−E
rrCanIn1_b
BOOL
binary
%IX111.0.0
˘
˘
CANaux1_IN
communication error
CANaux_bCe12Comm−E
rrCanIn2_b
%IX111.0.1
CANaux2_IN
communication error
CANaux_bCe13Comm−E
rrCanIn3_b
%IX111.0.2
CANaux3_IN
communication error
CANaux_bCe14BusOffSt
ate_b
%IX111.0.3
CAN bus "Off State"
detected (CAN bus
interface X14)
CANaux_byNode−Addres
s
Byte
˘
%IB111.2
C2450
˘
Node address
(CAN bus interface X14)
CANaux_byState
%IB111.3
C2459
˘
CAN bus status
(CAN bus interface X14)
13.11.2
Outputs_CANaux_Management
System variables
Variable
Data
type
Signal
type
Address
Display
code
Display
format
Comments
CANaux_bResetNode_b
BOOL
binary
%QX111.0.0
˘
˘
Carry out reset node
(CAN bus interface X14)
CANaux_bTxCan2Synchr
onized_b
%QX111.0.1
Transmit CANaux2_OUT
with sync telegram.
CANaux_bTxCan3Synchr
onized_b
%QX111.0.2
Transmit CANaux3_OUT
with sync telegram.
