Troubleshooting and fault elimination
Fault messages
Overview of fault messages, error sources and responses
12
l
242 EDBCSXA064 EN 3.2
12.3 Fault messages
12.3.1 Overview of fault messages, error sources and responses
System error message Possible settings/response
· Lenze setting
ü Setting possible
Available in
No. Display Source Meaning Code TRIP Messa
ge
Warni
ng
FAIL−Q
SP
Off Drive
PLC
Servo
PLC
ECSxA
x011 OC1 MCTRL Short circuit in motor cable · ь ь
x012 OC2 MCTRL Earth fault in motor cable · ь ь
x015 OC5 MCTRL I x t overload · ь ь
x016 OC6 MCTRL I 2 x t overload (C0120) · ü
x017 OC7 MCTRL I x t warning (C0123) C0604 ь · ь ь
x018 OC8 MCTRL I 2 x t warning (C0127) C0605 ь · ь ь
x020 OU MCTRL Overvoltage in the DC bus · ь ь
x030 LU MCTRL Undervoltage in DC bus · ь ь
x032 LP1 MCTRL Motor phase failure C0597 ь ь · ь ь
x050 OH MCTRL Heatsink temperature higher
than fixed limit temperature · ь ь
x051 OH1 MCTRL Interior temperature > 90° C · ü
x053 OH3 MCTRL Motor temperature higher
than fixed limit temperature C0583 · ь ь ь
x054 OH4 MCTRL Heatsink temperature higher
than variable limit
temperature (C0122) C0582 · ь ь ь
x055 OH5 MCTRL Interior temperature > C0124 C0605 ь · ь ь
x057 OH7 MCTRL Motor temperature higher
than variable limit
temperature (C0121) C0584 · ь ь ь
x058 OH8 MCTRL Motor temperature via inputs
T1/T2 is too high C0585 ь ь · ь ь
x061 CE0 AIF Communication error − AIF
module
óPLC
C0126 ь ь · ь ь ь
x062 CE1 CAN1 CAN1_IN (monitoring time can
be set with C0357/1) C0591
ь ь · ь ь ь
x063 CE2 CAN2 CAN2_IN (monitoring time can
be set with C0357/2) C0592
x064 CE3 CAN3 CAN3_IN (monitoring time can
be set with C0357/3) C0593
x065 CE4 CAN CAN BUS−OFF status
(too many faulty telegrams
received) C0595 ь ь · ь ь ь
x066 CE5 CAN CAN time−out (gateway
function C0370) C0603 ь ь · ь ь ь
x: 0 = TRIP, 1 = Message, 2 = Warning, 3 = FAIL−QSP
