System modules
DFOUT_IO_DigitalFrequency (node number 22)
Inputs_DFOUT / Outputs_DFOUT
13
l
340 EDBCSXA064 EN 3.2
13.17.1.1 Configure encoder constant
Via C0030 you configure the encoder constant:
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
C0030 DFOUT const 3 Constant for the digital
frequency signal DFOUT_nOut_v
on X8 in increments per
revolution ^ 340
^ 115
^ 122
0 256 incr./rev
1 512 incr./rev
2 1024 incr./rev
3 2048 incr./rev
4 4096 incr./rev
5 8192 incr./rev
6 16384 incr./rev
