System modules
DFOUT_IO_DigitalFrequency (node number 22)
Inputs_DFOUT / Outputs_DFOUT
13
l
339 EDBCSXA064 EN 3.2
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
C0030 DFOUT const 3 Constant for the digital
frequency signal DFOUT_nOut_v
on X8 in increments per
revolution ^ 340
^ 115
^ 122
0 256 incr./rev
1 512 incr./rev
2 1024 incr./rev
3 2048 incr./rev
4 4096 incr./rev
5 8192 incr./rev
6 16384 incr./rev
[C0491] X8 in/out 0 Function of X8 ^ 331
^ 115
^ 122
0 X8 is input
1 X8 is output
[C0540] X8 Signal out 2 Function of the digital frequency
output signals on X8 (DFOUT)
^ 112
0 DFOUT in [%]
1 DFOUT in [rpm]
2 Encoder simulation + zero pulse ®
DFOUT
C0545 PH offset 0 Phase offset ^ 340
0 {1 inc} 65535 1 revolution = 65535 increments
C0547 DIS: AN−IN Analog signal on the input of the
DFOUT block
Read only ^ 340
−199.99 {0.00 %} 199.99
C0549 DIS: DF−IN Speed on the input of the DFOUT
block
Only display ^ 340
−32767 {1 rpm} 32767
