System modules
MCTRL_MotorControl (node number 131)
Inputs_MCTRL
l
353
EDBCSXA064 EN 3.2
Comments
Display
format
Display
code
Address
Signal
type
Data
type
Variable
MCTRL_bResolverFault_b
BOOL
binary
%IX131.0.8
˘
˘
Monit: resolver error
MCTRL_bEncoderFault_b
%IX131.9.1
Monit: Encoder error
MCTRL_bSensorFault_b
%IX131.9.0
Monit: Thermal sensor
error
MCTRL_bMotorTempGre
aterSetValue_b
%IX131.0.11
Monit: Motor
temperature > 150 °C
MCTRL_bMotorTempGre
aterC0121_b
%IX131.0.12
Monit: Motor
temperature > C0121
MCTRL_bKuehlGreaterSe
tValue_b
%IX131.0.14
Monit: Heatsink
temperature > 85 °C
MCTRL_bKuehlGreaterC0
122_b
%IX131.0.15
Monit: Heatsink
temperature > C0122
MCTRL_bRotorPositionFa
ult_b
%IX131.9.3
Monit: Error during rotor
position adjustment
MCTRL_bMotorphaseFail
_b
%IX131.9.4
Monit: Failure of a motor
phase
