C0150 Status word
0
Device status word 1 (DCTRL)
Read only
^ 328
^ 239
0
{1}
65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0
Not assigned
DCTRL_bStateB0_b
Bit 1
Pulse inhibit (IMP)
DCTRL_bImp_b
Bit2
Not assigned
DCTRL_bStateB2_b
Bit3
Not assigned
DCTRL_bStateB3_b
Bit4
Not assigned
DCTRL_bStateB4_b
Bit5
Not assigned
DCTRL_bStateB5_b
Bit 6
n = 0
DCTRL_bNActEq0_b
Bit 7
Controller inhibit (CINH)
DCTRL_bCInh_b
Bit 8
Device status bit 1
DCTRL_bStat1_b
Bit 9
Device status bit 2
DCTRL_bStat2_b
Bit10
Device status bit 3
DCTRL_bStat4_b
Bit11
Device status bit 4
DCTRL_bStat8_b
Bit12
Warning
DCTRL_bWarn_b
Bit13
Message
DCTRL_bMess_b
Bit14
Not assigned
DCTRL_bStateB14_b
Bit15
Not assigned
DCTRL_bStateB15_b
C0155 Status word 2
0
Status word 2 (advanced status
word)
Display only
0
{1}
65535 Controller interprets information
as 16 bit (binary coded)
Bit 0
Active fault
Bit 1
M
max
reached
Bit 2
I
max
reached
Bit 3
Pulse inhibit(IMP)
Bit 4
Ready for operation (RDY)
Bit 5
Controller inhibit (CINH)
Bit 6
TRIP active
Bit 7
Initialisation
Bit 8
Motor direction of rotation (Cw/CCw)
Bit 9
Not assigned
Bit 10
Not assigned
Bit 11
Not assigned
Bit 12
Not assigned
Bit 13
Not assigned
Bit 14
Not assigned
Bit 15
Not assigned
