Chapter 1 An Overview of the Shake User Interface 73
The parameters indicator appears on the right side of the node, and the node’s
parameters are loaded into the Parameters2 tab. The node does not have to be
selected in order to load its parameters into the Parameters2 tab.
Loading a node’s parameters into a tab automatically clears out whatever previous
parameters were loaded. If necessary, you can clear a Parameters tab at any time.
To clear a tab so that no parameters are loaded into it:
m Right-click the Parameters1 or Parameters2 tab, then choose Clear Tab from the
shortcut menu.
It’s important to bear in mind that you can load the image from one node into the
Viewer, while loading another node’s parameters into the Parameters tab.
Click to load node
parameters.
Click once to display node in Viewer.
Double-click to load node parameters.
