Configuring the switch

82

To set fabric parameters:

NOTE:

The switch must be offline to change parameters in this dialog box. If it is not and you

activate values in this dialog box, a dialog box appears, prompting you to set the unit offline.

CAUTION:

Setting the switch offline terminates all Fibre Channel connections.

1.

Set the unit offline:
a. Select Maintenance > Set Online State. The Set Online State dialog box appears.
b. Click Set Offline. A warning box appears asking you to confirm the offline state.
c. Click OK.

2.

Select Configure > Operating Parameters > Fabric Parameters. The Configure

Fabric Parameters dialog box appears.

Figure 26

Configure Fabric Parameters dialog box (Edge Switch 2/32)

NOTE:

Ordinarily, you do not need to change values in this dialog box from their defaults.

Change the values if the switch will participate in a multiswitch fabric.

3.

Use information under ”

Fabric Parameters

” on page 83 to change settings as required for

parameters in this dialog box.

4.

After you change settings, click the Activate button.
