Edge Switch Element Manager user guide

73

You can display the FRU Properties dialog box for a specific FRU by using one of the following

methods:

Double-click on the FRU row.

Click a row in the FRU List View and then select Product > FRU > Properties.

Port operational states

Table 4

describes the port operational states and the LED and attention indicators that display in

the Hardware View and Port List View.

Table 4

Port states and indicators

Port state

Green/blue

port indicator

Amber port

indicator

Alert

indicator

*

Description

Beaconing

Off or On

Blinking

Yellow
Triangle

The port is beaconing. The amber port LED blinks
once every two seconds to enable users to find a
specific port. Enable beaconing through the port’s
menu on the

Hardware View

,

Port List View, or

Performance View.

Inactive

Off

Off

Yellow
Triangle

The switch port is in an inactive state. Reasons for
this state display in the Reason field of the Port
Properties dialog box.

Note that if port optics have also failed, the amber
LED will be on.

Invalid
Attachment

On

Off

Yellow
Triangle

The switch port is in an invalid attachment state.
Reasons for this state display in the Reason field of
the Port Properties dialog box.

Link Incident

Off

Off

Yellow
Triangle

A link incident occurred on one of the ports and
displays in the Port List View, with a corresponding
indicator displaying for the card in the Hardware
View.

Link Reset

Off

Off

Yellow
Triangle

The switch and the attached device are performing a
link reset operation to recover the link connection.
Ordinarily, this is a transient state that should not
persist.

No Light

Off

Off

None

No signal (light) is being received on the switch port.
This is a normal condition when there is no cable
plugged into the port or when the power of the
device attached to the other end of the link is off.

Not
Operational

Off

Off

Yellow
Triangle

The switch port is receiving the Fibre Channel not
operational sequence (NOS) indicating that the
attached device is not operational.
