GSP-930 User Manual

88

Move Delta Marker(s)Manually

Move Delta or
Reference Marker

1. Press

Marker

> Delta[F4]> Move[F2]>Move Ref[F2]

to move the reference marker.

2. Press

Marker

> Delta[F4]> Move[F2]>Move

Delta[F3] to move the Delta marker.

3. Move the selected marker in the same fashion

as a normal marker, see page 86

Move Both
reference and
delta marker

1. Press either Move Pair Span[F4] or Move Pair

Center[F5] to move both markers at the same
time.

Move Pair Span:

Sets the frequency span
between both markers.
The span can be positive
or negative:

1

+span

Δ1

Δ1

-span

1

Move Pair Center:

Moves both markers at
the same time, keeping
the span between both
markers even
throughout.

2. Move both markers in the same fashion as a

normal marker, see page 86
