APPENDIX
231
IF Bandwidth
300kHz
LPF>
Bypass
Time Axis>
Depth Axis>
AF Trigger>
Return
Bypass
3kHz
5kHz
23kHz
150kHz
200kHz
Ref. Value
0.0ns
Ref. Pos
5
Scale/Div
10.00ms
Auto Scale
On Off
Return
Ref. Value
30Hz
Ref. Pos
5
Scale/Div
10 %
Auto Scale
Return
Free Run
Edge Slope
Rising Falling
Trigger Mode
Nor. Sgl. Cont.
Trigger Level
10 %
Trigger Delay
50 ms
Run Now
Return
From: Measure>Demod>AM
Analysis
Decimation
frequency*
AM Analysis
On Off
Setup>
Min/Max Reset
* see page 120 for the selectable LPF filter bandwidths.
