3GPP-FDD BS For the FDD configuration, different limits can by
chosen based on the total channel power, P.
The default value for Δfmax is 12.5MHz. Δfmax can be
user-defined.
The channel span is set to 5MHz.
Note: A, B, C, D, E denote offsets 1 to 5, respectively.
P≥43
Unit: MHz Abs [1] RBW
2.5 ≤A<2.7 -14dBm 30kHz
2.7≤B<3.5 -14 ~ -26dBm 30kHz
3.5≤C<Δfmax -13dBm 1MHz
39≤P<43
Unit: MHz Abs [1] RBW
2.5 ≤A<2.7 -15dBm 30kHz
2.7≤B<3.5 -14 ~ -26dBm 30kHz
3.5≤C<7.5 -13dBm 1MHz
7.5≤D<Δfmax P-56dB 1MHz
31≤P<39
Unit: MHz Abs [1] RBW
2.5 ≤A<2.7 P-53dB 30kHz
2.7≤B<3.5 P-53dB~
P-56dB 30kHz
3.5≤C<7.5 P-52dB 1MHz
7.5≤D<Δfmax P-56dB 1MHz
P<31
Unit: MHz Abs [1] RBW
2.5 ≤A<2.7 -22dBm 30kHz
2.7≤B<3.5 -22 ~ -34dBm 30kHz
3.5≤C<7.5 -21dBM 1MHz
7.5≤D<Δfmax -25dBm 1MHz
