ADVANCED OPERATION
171
the set TG Level and increases/decreases
linearly to the set Power Sweep level at the end
of the sweep.
Range: -5dB to +5dB
Normalize the Tracking Generator
Background The normalize function subtracts the trace after
each sweep with a reference trace. The resultant
trace is added to a normalized reference level.
Operation 1. Press
System
>More 1/2[F7]>Option[F1]>Tracking
Generator[F1]>TG[F1] and toggle the tracking
generator on.
2. Press Normalize[F6] to enter the Normalization
menu.
3. Press Norm. Ref. Level[F2] to set the vertical level
of the normalized reference.
Range: 0dB~100dB
4. Press Norm. Ref. Position[F3] offsets the
normalized trace on the screen.
Range: 10~0 grid divisions.
(top to bottom)
