GSP-930 User Manual
72
Trace
The GSP-930 is able to set the parameters of up to 4 different
trances on the display at once. Each trace is represented by a
different color and is updated with each sweep.
Selecting a Trace
Description Each trace (1, 2, 3, 4) is represented by a
different color. When activated, an icon for each
trace color and function is shown to the left of
the display. When a trace is selected,
parameters can be set/edited from the trace
menu.
Trace Color: 1: Yellow
2: Pink
3: Blue
4: Red
Trace Type The type of trace used determines how the trace
data is stored or manipulated before being
displayed. The analyzer updates each trace
according to the type of trace used.
Clear and
Write The GSP-930 continuously
updates the display with each
sweep.
Hold Max/
Hold Min The maximum or minimum
points are maintained for the
selected trace. The trace points
are updated each sweep if new
maximum or minimum points
are found.
